Twin Bar Stability: Dual parallel wheel arrangement enhances stability for heavy, oversized loads.
Hand Chain Precision: Gear-driven mechanism enables exact positioning without manual pushing.
High Capacity Range: Engineered for loads from 500kg up to 50 tonnes in demanding applications.
Heavy Duty Design: Superior stability compared to single bar trolleys for industrial lifting.

Technical Data
Safe Use of Trolley

*Twin-Shaft Design: Distributes massive loads evenly, preventing twisting and tilting.

Product Features

Extreme Load Capacity: Precision engineered to handle massive loads ranging from 0.5 Ton up to 50 Ton, ideal for heavy machinery moving and infrastructure projects.
Superior Twin-Bar Stability: The double bar (twin shaft) design ensures equal load distribution across all wheels, preventing the trolley from tilting or twisting under heavy loads.
Precise Positioning: Powered by a geared hand chain mechanism, allowing operators to position extremely heavy loads with millimeter-level accuracy and minimal effort.
Enhanced Safety: Equipped with anti-jump bars and anti-drop plates as standard features to prevent derailment and wheel damage.
Smooth Operation: High-quality sealed ball bearing wheels ensure smooth traversing even at maximum capacity (50t).
Universal Beam Fit: Flexible adjustment system fits a wide range of I-beam and H-beam flange widths (Standard and Extended ranges available).
Durable Build: Robust steel construction with a durable painted finish withstands the rigors of heavy industrial environments.

H-Lift Trolley Selection Guide

Series	Drive	Capacity	Key Advantage	Application
PT-CA Type	Push	0.5T - 10T	Standard. Economical & stable.	General factory use (< 3 Ton).
GT-CA Type	Geared	0.5T - 10T	Standard. Precise positioning.	Loads > 3 Ton or high ceilings.
PT-DB Type	Push	0.5T - 10T	Twin Bar. Extra stability.	Wide beams / Anti-tilt needed.
GT-DB Type	Geared	0.5T - 50T	Twin Bar. Ultra-heavy capacity.	Heavy machinery, 20T+ loads.

Technical Specifications

*Refer to the diagram above to identify dimensions A through M in the table below.

Item No.	Capacity	Proof Load	Beam Width (mm)		Dimensions (mm)													Net Weight (kg)		Product Code
	Capacity	Proof Load	Std (a)	Ext (b)	A (Std)	A (Ext)	B	C	D	E	F	G	H	J	K	L	M	Std (a)	Ext (b)
	(t)	(kN)	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
GTDB005	0.5	7.35	50-152	50-203	240	290	200	190	108	53	94	18.5	78	57	37	14	24	10.0	11.0	130600500
GTDB010	1.0	14.7	64-203	64-305	310	395	238	211	115	59	120	24.0	90	66	40	16	28	14.5	16.0	130601000
GTDB020	2.0	29.4	88-203	88-305	320	425	274	236	130	69	136	26.0	105	75	44	17	34	20.0	23.0	130602000
GTDB030	3.0	44.1	100-203	100-305	330	435	314	295	164	82	150	33.0	130	96	60	17	34	30.0	35.0	130603000
GTDB050	5.0	73.5	114-203	114-305	350	450	364	334	177	97	169	38.0	150	112	65	22	40	45.0	51.0	130605000
GTDB100	10.0	147.0	124-203	124-305	362	462	480	460	237	130	198	55.0	189	150	90	27	57	107.0	115.0	130610000
GTDB200	20.0	245.0	136-203	136-305	392	512	565	495	240	148	268	55.0	225	175	110	56	80	165.0	188.0	130620000
GTDB300	30.0	367.5	175-305	/	512	/	625	564	258	164	296	60.0	255	196	125	76	90	230.0	/	130630000
GTDB500	50.0	612.5	175-305	/	512	/	625x2	564	258	164	296	60.0	255	196	125	76	90	610.0	/	130650000

*Note: a = Standard Beam Range; b = Extended Beam Range.

Push Trolley (PT-CA Type)

Geared Trolley (GT-CA Type)

Plain Trolley (PT-FA Type)

What is a Travel Trolley?

A push or geared travel trolley is a device designed to move heavy loads horizontally along an I-beam or similar track. It consists of a frame, wheels (rollers), and a suspension point for attaching a hoist or load.

Push vs. Geared: Which one to choose?

Push (Plain) Trolley: Best for infrequent movement or relatively light loads (typically up to 3 tons). Suitable where the beam height is below 6m (20ft). The operator simply pushes the load to move it.
Geared Trolley: Recommended for heavier loads (over 3 tons), higher beam elevations (>6m), or where precise positioning is required. Operated by pulling a hand chain which drives the wheels via gears.

H-Lift Ultimate Beam Trolley Selection Guide

Find the perfect trolley for your specific lifting application using the comparison table below:

Series	Drive Type	Capacity	Key Advantage	Recommended Application
PT-CA Type	Push	0.5T - 10T	Standard (Spacer Adj). Economical & stable.	Permanent installation. General factory use. Loads < 3 Ton.
GT-CA Type	Geared	0.5T - 10T	Standard (Spacer Adj). Precise load positioning.	Permanent installation. Loads > 3 Ton or high ceilings (>6m).
PT-FA Type	Push	0.5T - 5T	Quick Install. Threaded rod adjustment.	Maintenance teams. Temporary rigging. Frequent location changes.
GT-FA Type	Geared	0.5T - 5T	Quick Install. Threaded rod adjustment.	Maintenance teams needing precise positioning. Temporary use.
PT-DB Type	Push	0.5T - 10T	Twin Bar. Superior stability & anti-tilt.	Wide beams. Applications requiring extra stability against side-loading.
GT-DB Type	Geared	0.5T - 50T	Twin Bar. Ultra-heavy duty capacity.	Heavy machinery moving. Bridge construction. The only choice for 20T+ loads.
TCPS Type	Clamp	2T - 6T	Integrated Shackle. Self-aligning & fast setup.	Portable lifting points. Applications requiring a pivoting shackle connection.

Safety Guidelines

Always

Store and handle trolleys correctly in a clean, dry area.
Inspect trolleys, blocks, and accessories before use.
Ensure the wheel profile matches the track/beam type.
Verify the trolley width is correctly set for the beam width.
Ensure the track is fitted with positive end stops.
Push (rather than pull) loads suspended on push trolleys.

Never

Never expose trolleys to chemicals (like acids) without consulting the supplier.
Never force or wedge the suspension hook onto the load bar.
Never throw or drop a trolley.
Never use a trolley with chipped or damaged wheel flanges.
Never obliquely side load a trolley (this can cause tipping or detachment).

Installation & Maintenance Guide

Installing and Commissioning

Ensure the runway track is level and has an even surface. Check that positive end stops are installed. Verify the trolley width is set correctly with spacers centered. Confirm anti-tilt devices are properly adjusted. If re-assembling, ensure all bolts and nuts are fully tightened.

Using Trolleys Safely

Do not side load! The trolley must be placed directly over the center of gravity of the load. Oblique side loading causes tipping and can lead to the trolley falling off the track. For push trolleys, push the load rather than pulling it to maintain better control.

In-service Inspection

Regularly inspect for wear on wheel treads and flanges. Check for insecure wheels, loose axle pins/nuts, or distorted side plates. Ensure hand chains (on geared models) are not damaged. Keep wheel running surfaces clean and free of oil/grease contamination to ensure traction.

Download

Brand & Trust: Company Profile; ISO 9001 Certificate of Approval; LEEA Certificate of Membership; Our Certificates; Terms of Use

Contact Us

8/F No. 560 Jincheng Road, Xiaoshan, Hangzhou, 311202, China

info@h-lift.com

+86-571-8263 6008

Quick Links: Our Products

Our Blogs

Case Studies

News & Events

We use cookie to improve your online experience. By continuing browsing this website, we assume you agree to our use of cookie.

H-Lift | Global Rigging Solutions

Access Restricted: JavaScript Required

To protect our proprietary engineering data and ensure a secure browsing experience, the H-Lift website requires JavaScript to be enabled.

Please enable JavaScript in your browser settings and refresh the page to continue.

Double Bar Geared Trolley GT-DB type
