The H-Lift European Type Large Bow Shackle is an oversized, O-shaped connecting link designed to provide extra internal clearance for secure, multi-directional rigging and marine attachments.

Features an expanded bow profile with a wider internal area, easily accommodating multiple slings, thicker ropes, or larger hardware assemblies.
Constructed from heavy-duty forged steel to provide superior strength and reliable load-bearing capacity in rigorous environments.
Designed for multi-directional loading, making it safer for angled pulls compared to standard D-shackles.
Equipped with a convenient threaded screw pin for quick and secure attachment during temporary or semi-permanent rigging operations.

Technical Data
Safe Use of Shackles

The European Type Large Bow Shackle is a versatile, commercial-grade rigging component designed for general utility, towing, and light lashing. Its oversized rounded geometry provides significant internal clearance, making it the ideal choice for connecting multiple lines or bulky fittings that would overcrowd a standard shackle.

⚠️ SAFETY WARNING: COMMERCIAL GRADE - NOT FOR OVERHEAD LIFTING.
These shackles are commercial pattern and are not rated for critical industrial overhead lifting. They are intended for lashing, fishing gear, and general non-safety-critical hardware applications.

📐 Oversized Bow Geometry

Features a significantly larger and rounder "bow" than standard shackles. This expanded internal area provides ample room for multiple sling legs and large hooks without overcrowding the hardware.

⚙️ Balanced "Same-Size" Design

Engineered with a pin diameter that matches the body diameter. This balanced configuration ensures reliable load distribution and consistent mechanical strength across the entire assembly.

🛡️ Weather-Resistant Finish

Protected by a bright electro-galvanized coating, providing essential corrosion resistance for marine, coastal, and outdoor industrial environments.

⚓ Versatile Utility

Widely utilized on commercial trawlers and fishing vessels, as well as for general mooring and material handling where commercial-pattern hardware is industry standard.

Technical Specifications

← Swipe table left and right to view all data →

Item No.	Size (Body/Pin)	W.L.L.	Dimensions (mm)					Weight (kg)	Product Code
Item No.	Size (Body/Pin)	W.L.L.	A	B	C	D	E	Weight (kg)	Product Code
SH05005	5 MM	0.08 T	10	19	16	5	11	0.017	701005005
SH05006	6 MM	0.1 T	13	25	20	6	14	0.025	701005006
SH05008	8 MM	0.2 T	16	32	24	8	18	0.050	701005008
SH05010	10 MM	0.32 T	19	38	32	10	20	0.090	701005010
SH05012	12 MM	0.52 T	25	51	38	12	26	0.180	701005012
SH05014	14 MM	0.7 T	28	56	45	14	28	0.280	701005014
SH05016	16 MM	0.8 T	32	64	56	16	33	0.410	701005016
SH05018	18 MM	1 T	36	72	60	18	36	0.620	701005018
SH05020	20 MM	1.1 T	38	76	66	20	40	0.800	701005020
SH05022	22 MM	1.5 T	44	89	74	22	50	1.100	701005022
SH05025	25 MM	2.1 T	51	100	80	25	57	1.650	701005025
SH05028	28 MM	3 T	57	115	94	28	68	2.400	701005028
SH05032	32 MM	3.5 T	64	127	104	32	73	3.500	701005032
SH05036	36 MM	4 T	72	144	112	36	75	5.100	701005036
SH05038	38 MM	5 T	76	152	126	38	85	6.350	701005038
SH05042	42 MM	6 T	84	168	138	42	90	8.400	701005042
SH05045	45 MM	7 T	90	180	150	45	96	11.50	701005045
SH05050	50 MM	8 T	102	200	156	50	108	14.00	701005050

Q: Can I use a commercial European type shackle for critical overhead lifting? A: Generally, no. These shackles are commercial grade and often lack the 6:1 safety factor and rigorous testing required by standards like EN 13889. They are best suited for general rigging, lashing, and fishing gear where commercial-pattern hardware is locally accepted.

Q: What is the benefit of the "Large Bow" over a standard Dee shackle?A: The larger, rounded bow allows the shackle to handle multi-directional loads more safely. It also provides the necessary clearance to connect multiple sling eyes or large thimbles to a single point, which is physically impossible with the narrow throat of a Dee shackle.

Bolt Type Chain Shackle

Screw Pin Anchor Shackle

Bolt Type Anchor Shackle

Safety Guidelines

Always

Store and handle shackles correctly.
Inspect shackles before use and before placing into storage.
Select the correct pattern of shackle (Dee/Bow) and pin type for the application.
Fully tighten the pin before lifting.
Ensure the load acts through the centre line of the shackle.
Allow for the full resultant imposed load (consider angles).

Never

Use shackles with bent pins or deformed bodies.
Force, hammer, or wedge shackles into position.
Eccentrically load shackles (side loading).
Replace the pin with a standard bolt.
Fit pins in contact with moving parts which may unscrew them.
Shock load shackles.

Selection & Operation Guide

Selecting the Correct Shackle

Type: Use Anchor (Bow) shackles for multi-leg systems or where side loading may occur. Use Chain (Dee) shackles for straight-line pulls.

Pin Type:
• Screw Pin: Suitable for general, non-permanent purposes.
• Bolt Type (Safety Pin): Essential for long-term installations or where the pin may rotate under load.

⚠️ CAUTION: Loading on the Pin BS and ISO Standard shackles are rated for the pin to accept a central point load. Unless stated otherwise, assume the jaw must be fully filled and the load evenly distributed across the full pin width.

Using Shackles Safely

Avoid Side Loading: Position the shackle so the body takes the load along its center line. Use spacers if necessary to center the load on the pin.

Tightening: Tighten screw pins by hand, then lock with a small bar. Do not overtighten to the point of deforming the body. For bolt types, ensure the split cotter pin is fitted.

Choke Hitches: Place the pin through the eye of the sling. Never place the pin in contact with the "bight" of the choke or moving parts, as friction can unscrew the pin.

Maintenance & Storage

Storage: Store in a clean, dry place protected from corrosion. Never modify or galvanize a shackle without supplier approval.

Inspection: Check regularly for: distorted/stretched bodies, bent pins, damaged threads, nicks, gouges, or corrosion. illegible markings. If any defect is found, refer to a Competent Person.
