The H-Lift CTA type load skate combines steering capability with robust load support for efficient machinery transport. Its integrated turntable and handle allow precise maneuvering of heavy equipment in tight spaces, while high-quality rollers ensure smooth, low-resistance movement without damaging industrial floors.
The CTA Series Heavy Duty Skates combine extreme capacity with a compact footprint. Featuring a multi-roller design (up to 25 rollers), they distribute heavy loads evenly to protect floors. With capacities up to 30 Tonnes and a low profile of just 101mm, they are the safe choice for moving massive industrial machinery.
One of the widest capacity ranges available, from 6 Tonnes for general equipment up to 30 Tonnes for massive industrial plant machinery.
Designed with a high number of rollers to spread the load over a larger surface area. This significantly reduces ground pressure, preventing damage to workshop floors.
With a deck height as low as 101mm, these skates slide easily under toe-jacked equipment, keeping the center of gravity low for maximum safety.
Built with a fully welded steel body and powder-coated finish. Available with PU wheels for smooth operation or Steel wheels for rugged durability.
| Item No. | Capacity (t) | No. of Rollers | Skate Size (mm) (LxWxH) |
Weight (kg) | Product Code |
|---|---|---|---|---|---|
| CTA-06 | 6 | 4 | 287x220x101 | 12 | 801001006 |
| CTA-08 | 8 | 6 | 384x220x101 | 19 | 801001008 |
| CTA-12 | 12 | 8 | 478x220x101 | 25 | 801001012 |
| CTA-18 | 18 | 12 | 478x310x101 | 36 | 801001018 |
| CTA-20 | 20 | 16 | 500x397x115 | 55 | 801001020 |
| CTA-25 | 25 | 20 | 598x404x115 | 67 | 801001025 |
| CTA-30 | 30 | 25 | 585x486x110 | 81 | 801001030 |
Load moving skates, also known as machinery skates or equipment skates, are specialized tools designed for moving heavy loads horizontally. These skates are particularly useful in industrial and commercial settings where the relocation of heavy machinery or equipment is required.
They effectively reduce the need for cranes or forklifts in confined spaces and are typically used in conjunction with other lifting equipment, such as hydraulic jacks (toe jacks), to facilitate the loading process.
Common Applications:
The platform is constructed of sturdy steel to withstand heavy loads. The low-profile design ensures stability while maximizing overhead clearance.
Wheels vary in number and arrangement (e.g., square pattern or multi-row) to increase stability. Made from Nylon (for floor protection) or Steel (for durability).
Many models feature swivel casters or a turntable top, allowing for easy turning and positioning in tight spaces.
Some skates include a handle or pulling bar for manual push/pull operation. Adjustable models allow users to change connecting bar spacing for different load sizes.
| Type | Movement | Typical Application |
|---|---|---|
| Fixed Skates (Straight-Running) |
Moves in a straight line only. | Used under the rear of the load for stability. |
| Steerable Skates (Swivel) |
Rotating top plate allows turning. | Used at the front of the load for steering control. |
| Adjustable Skates | Connecting bars adjust width. | Accommodating loads of varying widths and sizes. |
| Powered Skates | Motor-driven (Electric/Pneumatic). | Precise movement of extremely heavy loads without manual pushing. |
To ensure safe operation and longevity of the equipment, follow these guidelines:
